| Capacities | Imperial | |||
|---|---|---|---|---|
| Max. capacity | Q | 5512 lbs | ||
| Max. lifting height | h3 | 19 ft 4 in | ||
| Max. outreach | l4 | 10 ft 10 in | ||
| Reach at max. height | 1 ft 8 in | |||
| Breakout force with bucket | 4205 daN |
| Weight and dimensions | ||||
|---|---|---|---|---|
| Unladen weight (with forks) | 10851 lbs | |||
| Ground clearance | m4 | 1 ft 3 in | ||
| Wheelbase | y | 7 ft 7 in | ||
| Overall length to carriage (with hitch hook) | l11 | 12 ft 10 in | ||
| Front overhang | 3 ft 3 in | |||
| Overall width | b1 | 5 ft 11 in | ||
| Overall cab width | b4 | 2 ft 7 in | ||
| Overall height | h17 | 6 ft 7 in | ||
| Tilt-down angle | a5 | 117 ° | ||
| Tilt-up angle | a4 | 12 ° | ||
| External turning radius (over tyres) | Wa1 | 10 ft 10 in | ||
| Standard tyres | Alliance - A580 - 300/75 R18 | |||
| Drive wheels (front / rear) | 2 / 2 | |||
| Steering wheels (front / rear) | 2 / 2 |
| Performances | ||||
|---|---|---|---|---|
| Lifting | 7.3 s | |||
| Lowering | 4.95 s | |||
| Extension | 5.2 s | |||
| Retraction | 3.7 s | |||
| Crowd | 3.2 s | |||
| Dump | 3.2 s |
| Engine | ||||
|---|---|---|---|---|
| Engine brand | Kubota | |||
| Engine norm | Stage V | |||
| Engine model | V3307-CR-T-E5B | |||
| Number of cylinders - Capacity of cylinders | 4 - 203.27 in³ | |||
| I.C. Engine power rating / Power (kW) | 75 Hp / 55.4 kW | |||
| Max. torque / Engine rotation | 265 Nm @1400 tr/min | |||
| Drawbar pull (Laden) | 3240 daN | |||
| Reversible fan | Standard | |||
| Engine cooling system | 2 radiators water hydraulic oil |
| Transmission | ||||
|---|---|---|---|---|
| Transmission type | Hydrostatic | |||
| Number of gears (forward / reverse) | 2 / 2 | |||
| Max. travel speed (may vary according to applicable regulations) | 15.5 mph | |||
| Differential lock | Limited slip differential on front axle | |||
| Parking brake | Automatic negative parking brake | |||
| Service brake | Oil-Immersed multi-discs braking on front axles |
| Hydraulics | ||||
|---|---|---|---|---|
| Hydraulic pump type | Gear Pump | |||
| Hydraulic flow - Pressure | 86 l/min - 16 PSI |
| Tank capacities | ||||
|---|---|---|---|---|
| Hydraulic oil | 25.30 gal | |||
| Fuel tank | 13.86 gal |
| Noise and vibration | ||||
|---|---|---|---|---|
| Noise at driving position (LpA) tested following NF EN 12053 norm | 76 dB(A) | |||
| Environmental noise (LwA) | 104 dB(A) | |||
| Vibration to whole hand/arm | < 2.50 m/s² |
| Miscellaneous | ||||
|---|---|---|---|---|
| Safety tractor homologation / cabin homologation | Cab ROPS - FOPS Level 1 | |||
| Controls | JSM |
